100w 80w 40w Co2 Laser Engraving Cutting Machine For Metal Leather Acrylic Wood

Product Categories

PSL (WUHAN) SMART EQUIPMENT CO.LTD.

Contact Now

100w 80w 40w Co2 Laser Engraving Cutting Machine For Metal Leather Acrylic Wood

Brand Name : PSL

Model Number : HQ1325M

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 30 sets per month

Delivery Time : 30-45 days

Packaging Details : Wooden case, or Naked into container

Product name : CNC CO2 Laser Cutting & engraving machine

Machine type : HQ1325M

Condition : New

Application : Metallic and Non-metallic materials Manufacturing Plant, Advertising industries,Hardware, Furniture

Keyword : CO2 Laser Cutting machine, CO2 Laser cutter, CO2 laser engraving machine

Key Selling Points : Automatic easy to operate, cutting metal sheet and non-metal, glass, wooden, bamboo

Function : Metallic & Non-metallic sheet cutting, Metal sheet tube Laser Cutting

Cnc or not : Yes

Operation system : Touch screen

Laser source : CO2 Laser Tube

Laser power : 100W,150W,200W,300W

Laser mode : Continuous

Working table : 1250x2500mm

Max.cutting thickness : 0.5-2mm metal sheet, 0.5-20mm non-metal materials

Cooling mode : Circle Water Chiller,Water-cooling and protection system

Focus adjusting : None, or automatic adjusting focus optional

applied software : CorelDraw,Photoshop,AutoCAD,CAM

Cutting materials : Metallic and Non-metallic sheet/plate

Dimensions : 3.1*1.8*1.4m

Color : Standard color, or Customized

Weight of machine : 1500kg

Maintenance : Remote online diagnosis and detection

Warranty : 1 Years

After-sales service provided : Engineers available to service machinery overseas

Certification : CE, ISO,SGS,CCC

Contact Now

CO2 CNC Laser Cutting and engraving machine processing metal & non-metal materials

Main feature discription:

1. English version Laser cut software supporting 10 commonly used graphic formats.

2. DSP off-line control with USB port interface

3. Imported focusing lenses, choice of 4", 2.5" focal lengths.

4. Focusing is simple by touching two button, takes only 3 seconds, automatic focusing is optional.

6. All models feature a red dot alignment pointer, helping to properly position your work under the laser head

7. Un-limited feed-through door , we can only add the auto-feeding system allows the use of roll material and unlimited sheet length

8. Air asist ,we will provide one set air compressor, you can turn up/down the switch between the laser head to control the strength of air blowing. To avoid getting fired and blow away the dusk /smoke.

9. Exhaust fan & vacuum table, this pulls fumes and debris away from the work piece; the resulting vacuum is strong enough to straighten and flatten thin materials against the work table for cutting and engraving in good focus.

10. The machine includes one set EXLAS, exhaust fan, air assist compressor , one tool box, CD friendly training video and user macnual,and one year warranty.

Technical parameters of CO2 laser marking & cutting machine:

Item	Specification
Application	LASER CUTTING & ENGRAVING
Applicable Material	Acrylic, Glass, Leather, MDF, Metal, Paper, Plastic, Plexiglax, Plywood, Rubber, Stone, Wood, Crystal Metal carbon steel, stainless steel, aluminum sheet,etc...
Laser Type	CO2
Cutting Area	1250x2500mm
Cutting Speed	0-1000mm/S
Graphic Format Supported	AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
Cutting Thickness	0-20mm(depends on non-metal material)
Cutting thickness of Metal materials	0-2mm
CNC or Not	Yes
Cooling Mode	WATER COOLING
Control Software	ezcad
Place of Origin	China
Laser Source Brand	RECI
Servo Motor Brand	Leadshine
Guiderail Brand	HIWIN
Control System Brand	RuiDa
Weight (KG)	1200KG
Key Selling Points	High-accuracy
Warranty	2 years
Machinery Test Report	Provided
Video outgoing-inspection	Provided
Core Components	laser tube
Mode of Operation	continuous wave
Configuration	gantry type
Products handled	Sheet and Tube Metal
Feature	Water-cooled
Working table	Honey comb/ Electrical up and down/ knife
Power Supply	220V/50Hz/60Hz
Min line width	≤0.15mm
Positon accuracy	0.01mm
Repetition accuracy	0.02mm
DPI	1000dpi
Smallest Character Engraving	Character2.0mmx2.0mm, English 1.0mmx1.0mm
Transmission method	Belt or Gear rack & pinionTransmission
Control software	CORELDRAW, Photoshop, AutoCAD, etc
Working environment	0-45℃

Applicable Industries:

Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company

All kinds of metal materials, as Carbon steel, stainless steel, iron plate, titanium plate
